Name: Máquina de espumado y sellado de campo WINMAN WM-508 (FIPFG): excelente relación costo-beneficio, adecuada para el sellado de pequeños armarios de control eléctrico y cajas de conexiones.
Brand: Winman Industrial

Home / Product center / WINMAN WM-508 Field Foaming and Sealing Machine (FIPFG) - High cost-performance ratio, suitable for sealing small electrical control cabinets and junction boxes.

 

https://shmuker.oss-accelerate.aliyuncs.com/data/oss/60f07f852d555b4a10663d68/69d4608fe3f5075943ecb4e2/20260414160854/pu-foam-gasket-dispensing-machine-wm-508.png

Product Details

The WINMAN WM-508 FIPFG Automatic Foam Sealing Machine is a high-precision dispensing system designed specifically for small electrical control cabinets and junction boxes, combining German FIPFG molding technology with the advantages of localized manufacturing. This equipment boasts a dispensing accuracy of ±0.01% and a maximum foaming speed of 300mm/s, achieving IP67 dustproof and waterproof sealing, and increasing production efficiency by over 40%. Utilizing a dual return head structure and a German Sonderhoff control system, it supports 24-hour continuous operation with an energy consumption of only 3.5KW, making it energy-efficient and environmentally friendly. WINMAN INDUSTRIAL (established in 2010) provides ISO9001 and CE certified products suitable for industries such as new energy vehicle batteries, photovoltaic energy storage, and automation equipment, meeting the global customer's needs for quality, stability, and scalability.

Customized price reference

Specific details： Please contact us

Payment method

COMM

Means of transaction

Communication

Core Functions and Advantages

Dosing Accuracy

Dispensing accuracy of ±0.01%, enabling ultra-precise sealing results.

Mixing Ratio Accuracy

AB mixing ratio accuracy of ±0.1%, ensuring consistent product formation.

Material Tank Capacity

Each A/B material tank has a capacity of 44 liters, significantly reducing refilling frequency.

Foaming Speed

Foaming speed from 0 to 200 mm/s, freely adjustable.

Operating Temperature Range

Operating temperature range from -15°C to 45°C, no air-conditioned room required.

Low Energy Consumption and Durability

Total machine power is 4 kW, reducing energy consumption by 50%. Core components have a service life of over 20 years, and one water wash supports 500 meters of continuous output.

Process Flow

Place the product on the tooling workbench.

The system automatically identifies the sealing path.

AB two-component formulation is precisely fed via a servo pump.

Dynamic mixing head for high-speed mixing

Anti-drip nozzle automatic dispensing foam

High-pressure water and air cleaning, one-time molding without the need for trimming.

Application industries

Electronics Precision Manufacturing

Miniature connectors, chip housings, precision electronic components

Connector manufacturing industry

High-precision connectors for electronics and automotive

Semiconductor packaging industry

Chip packaging and housing applications

Technical Parameters

Parameter Category	Parameter Name	Parameter Value
Core Equipment	Model	WM-508
	Precision	±0.01%
	Foaming Speed	0-300mm/s
	Control System	Germany Sonderhoff+PLC
	Material	PU Foam
Feeding & Ratio	AB Ratio	1:1-10:1
	Ratio Accuracy	±0.1%
	Mixing	Dynamic High-Speed
	Material Tanks	A=44L，B=44L
Operation Control	Operation	17-inch Touchscreen + Teach Pendant
Operation Control	Cleaning	High-Pressure Water + Air
General Parameters	Voltage	380V/50Hz
	Power	3.5KW
	Protection	Equipment IP54, Sealing IP67

Customer Cases

Air conditioner

WINMAN INDUSTRIAL Helps a Jordan HVAC Manufacturer Improve Efficiency with the WM-601 FIPFG Machine

WINMAN INDUSTRIAL supported a Jordan-based HVAC manufacturer facing material buildup, pipe clogging, and unstable semi-automatic sealing operations. By introducing the WM-601 FIPFG automatic foam dispensing machine with IPC control, automatic air replenishment, and remote maintenance support, the customer improved production efficiency, reduced defects, and lowered operating costs while stabilizing the sealing process.

Check the details

Electrical Equipment

WINMAN INDUSTRIAL WM-601 Case Study: Efficiency and Quality Upgrade for Low-Voltage Electrical Manufacturing in Kuwait

WINMAN INDUSTRIAL deployed the WM-601 FIPFG automatic foaming dispensing machine for a leading low-voltage electrical manufacturer in Kuwait, helping resolve material buildup and pipeline blockage issues found in semi-automatic equipment. With dynamic mixing, dual-core system control, and remote maintenance support, the project improved production efficiency, raised product consistency, and reduced operating costs in a high-standard electrical sealing application.

Check the details

New Energy Sources

WINMAN Industrial Helps a Dubai Electrical Customer Upgrade Cabinet Sealing with WM601 FIPFG Solution

WINMAN Industrial provided a customized WM601 FIPFG in-situ foaming sealing solution for a smart electrical and new energy customer in Dubai facing sealing instability, material clogging, and maintenance issues in high- and low-voltage cabinet production. The project helped improve production efficiency, reduce defects, and support more consistent outdoor electrical equipment sealing with remote maintenance and on-site programming support.

Check the details

Car

Tesla Door Module Panel FIPFG Sealing with WM601 Fully Automatic PU Dispensing

WINMAN INDUSTRIAL delivered a WM601 fully automatic two-component PU FIPFG sealing solution for Tesla’s vehicle control cabinet and door panel sealing application. The project addressed material buildup, clogged pipelines, and unstable semi-automatic production by introducing dynamic mixing, online metering, precise trajectory dispensing, and process control, helping improve line efficiency, reduce defects, and support more stable mass production.

Check the details
